Waterco MultiCyclone Plus MC12 c/w 40sqft. Cartridge
MultiCyclone Plus combines centrifugal and cartridge filtration into one streamlined housing, creating an ultra compact filtration system.
The MultiCyclone Plus combines centrifugal and cartridge filtration into one streamlined housing, creating an ultra compact filtration system.
Features- Dual stage filtration
- Minimal maintenance
- Save water and energy
- Pleated filter cartridge
Dual Stage Filtration
Incoming water tangentially enters its multiple hydro cyclones, generating a strong centrifugal effect. Approximately 80% of the incoming dirt load is spiralled down to its clear sediment chamber.
The outgoing water is finally polished via its inbuilt cartridge filter, producing crystal clear water.
Extended filter capacity
The MultiCyclone Plus’s centrifugal section filter pre-filters up to 80% of the incoming dirt load before it reaches the filter cartridge, magnifying the capacity of its filter cartridge by up to 5 times. The MultiCyclone Plus has a filtration capacity equivalent to a 200 ft² cartridge filter or a 24in (600mm) sand filter.
Ultra compact filtration
The MultiCyclone Plus’s streamlined design means the entire filtration system can be installed vertically, reducing the footprint of the equipment pad. Additionally, minimal pipework reduces the filtration system’s overall head loss. Alternatively the MultiCyclone Plus can be installed next to the pump by using the optional base.
Technical Information
| Connection Ports | 1½in / 50 mm |
| Minimum Flow Rate | 2.4 m³/h |
| Maximum Flow Rate | 9 m³/h |
| Filter Area | 40 ft² / 3.7 m² |
| Maximum Pool Size | 55,000ft³ / 55m³ |
| Maximum Pressure | 350kPa (50psi) 3.5 bar |
| Weight (kg) | 12 |
| SKU | 200380 |
|---|---|
| Re-stock date | Call For Availability |
| Manufacturer | Waterco |
| Filtration Range | Multi Cyclone |
| Discount Group | O |
